12V 460Ah | Heated & Bluetooth & Victron Comms | LiFePO4 Battery

12V 460Ah | Heated & Bluetooth & Victron Comms | LiFePO4 Battery

$1,799.00
$1,799.00
Sale Sold out
Shipping calculated at checkout.

12V 460Ah | Heated & Bluetooth & Victron Comms | LiFePO4 Battery

LiFePO4 Chemistry

Group 8D Size (20.9" x 8.7" x 12.1") L x W x H

460Ah Capacity

300A Max Continuous Discharge (500A 30s Discharge)

230A Max Continuous Charge (300A 10s Charge)

IP67 Rated, Dust and WATERPROOF

HEATED - Internal heating for below 0C charging

BLUETOOTH - iOS and Android Apps

CANBUS Communication allows BMS to communicate directly with Victron OS

Mountable ON/OFF Switch

Mountable Battery gauge

Optional mounting brackets

Built-in Smart Battery Management System (BMS)

500A internal fuse with 50,000A AIC

Over charge and over discharge protection

Over current and short circuit protection

High & low temperature disconnects

3500+ Cycle life & Maintenance-free

11 Year Manufacturer Warranty

Weight: 97 (LBS)

DIMENSIONS
Length: 20.75 (inches)
Width: 8.5 (inches)
Height: 12 (inches)

CONFIGURATION
Cell Configuration: 4S2P
Chemistry: LiFePO4
CURRENT
Ah Capacity: 460Ah
Max Continuous Discharge Amps: 300A
Max Charge Current Amps: 230A
Max Discharge Peak Current Amps: 500A (30 Seconds) , 1300A (1 Second)
Series | Parallel: Max (4) in Series OR Max (4) in Parallel - 4S1P or 1S4P
VOLTAGE
Voltage: 12.8V
Max Charge Voltage: 14.6V
Operating Voltage Range: 10.0 - 14.6V
TEMPERATURE
Charge Temp Range: -20°C (-4°F) / 55°C (131°F) (with heating)
Discharge Temp Range: -20°C (-4°F) / 60°C (140°F)
Storage Temp: 0°C (32°F) / 35°C (95°F)
